Lifting Solutions
We proud to announce the introduction of "Direct
Lift- A Rotary Brand-USA" in to our product portfolio. As a direct
importer, reseller & service provider, we are confident of the
quality, service back up & capability of the product
 |
| Model |
HS7000N(Surface mounted) |
| Lifting Capacity |
3175kg (7000 lbs.) |
| Lifting Height (without rubber pad) |
1820mm (71-5/8") |
| Minimum Height |
189mm (7-3/8") |
| Overall Width |
1960mm (77-1/8") |
| Overall Length |
4208mm (165-5/8") |
| Width of Platforms |
530mm (20-3/4") |
| Length of Platforms |
1450mm (57") |
| Width Between Platforms |
987mm (38-3/4") |
| Pulling Length of Arms |
525mm (20-5/8") |
| Motor Power |
2.2kw |
| Power Option |
3Ph/220v/50Hz - 60Hz |
|
|
|
| Model |
HPRO9D |
| Lifting Capacity |
4082kg (9000 lbs.) |
| Lifting Height |
2006mm (79") |
| Overall Height |
3619mm (142-1/2") |
| Overall Width |
3403mm (134") |
| Drive Through |
2343mm (92-1/4") |
| Inside Column |
2794mm (110") |
| Lifting Time |
45 seconds |
| Motor Power |
2.2kw |
| Power Option |
3Ph/220v/50Hz - 60Hz |
|
|
|
| Model |
HPRO9F |
| Lifting Capacity |
4082kg (9000 lbs.) |
| Overall Height |
111-1/4 |
| Overall Floor Width |
138-1/2 |
| Maximum Lift Height |
81 |
| Minimum Adapter Height |
4 |
| Between Columns |
111 |
| Drive Thru |
97-1/4 |
| Motor |
2 HP, 208-230 VAC, 1PH |
|
|
